NAAMS Shims and Spacers

NAAMS shims and spacers, fixture shims, NAAMS spacers, tooling shims, stack-up adjustment shims, welding fixture alignment shims, automation fixture spacers, NAAMS standard components

NAAMS shims are ideal for filling small gaps or spaces in your automation setups. These metric-fitting shims comply with North American Automotive Metric Standards and feature a slotted design for easy installation in tight spaces between components or workpieces. Available thicknesses include 0.25 mm, 0.50 mm, 1.00 mm, and 2.00 mm. The 0.50 mm shims have a yellow zinc dichromate coating, 1.00 mm shims come with a black oxide finish, while the 0.25 mm and 2.0 mm versions are uncoated and can be identified by their thickness. Shims not only help achieve a better fit but can also be used with spacers to fill gaps as needed. Contact Sales@freertool.com or 586-463-3200 for a quote.

NAAMS spacers are designed to fill larger gaps where shims aren’t sufficient. These metric spacers come in a variety of hole configurations: Series 200, 300, 400, and 500 feature adjacent holes, with the series number indicating the number of holes (e.g., Series 300 has three holes, Series 400 has four, and Series 500 has five). Series 600 spacers offer six holes, arranged as three parallel holes on each side. Narrow spacers, measuring 20 mm in width, are available in Series 300, 400, and 500. Slotted spacers also come in Series 300, 400, 500, and 600, all with a 20 mm width. Custom spacers are available upon request. Contact Sales@freertool.com or 586-463-3200 for a quote.

Aside from the standard series, our NAAMS spacer offerings also include a 3-slot construction spacer, mounting spacers, and shock bracket spacers. You can browse all of our NAAMS shims and spacers or see the full catalogs below.

At Freer Tool & Supply, we're able to offer both NAAMS shims and spacers at a great value without compromising quality with ISO 9001:2015 compliance.

Full catalogs can be found by following the links below.
NAAMS Shims
NAAMS Spacers
Complete NAAMS Catalog
