Brand: Iscar
Iscar EH5510366 WNMA 333 IC5005
SKU: FTS-EH5510366
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.
Short Description
Iscar 5510366 WNMA 333 IC5005Full Description
| Applicable Material | | Steel | Cast Iron | Hard Materials | | Grade | IC5005 |
| Application | | Ext. 80° Trigon 95° Approach | Insert | Int. 80° Trigon 95° Approach | | Tool Type | Turn Negative Inserts |
| Insert Style | WNMA | Min D.O.C. | 0.039" |
| Corner Radius (RE) | 0.0472" | Depth of Cut Maximum (APMX) | 0.118" |
| Insert Size | 333 | Min. Turning Feed (ft(min)) | 0.0012 "/rev |
| Cutting Edge Length (L) | 0.257" | Max. Turning Feed (ft(max)) | 0.0197 "/rev |
| Insert Thickness (S) | 0.187" | Chip Breaker Type | A |
| Inscribed Circle Diameter (IC) | 3/8" | Measurement Type | Inch |
| Cutting Edge Material | Carbide | Series/List # | WNMA 333-A |
| Coating | TiCN+Al2O3+TiN | Body Material | Carbide |
Family Description
Double-sided trigon inserts, used for short chipping materials such as cast iron.
For dimensions and tolerances, see more info.
