Brand: Raptor Workholding Products
Raptor RWP-234 Aluminum Riser Haas UMC-750/UMC-750SS Matsuura MX-520 (300mm) 11.40" Diameter, 4.50" Height
SKU: RPT-RWP-234
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*Please note, there is a $50 minimum for all Raptor product orders*
Short Description
Raptor RWP-234 Aluminum Riser Haas UMC-750/UMC-750SS Matsuura MX-520 (300mm) 11.40" Diameter, 4.50" HeightFull Description
Diameter in. | 11.40 |
---|---|
Height in. | 4.500 |
Machine Type | Haas UMC-750 / UMC-750SS, Matsuura MX-520 (300mm) |
Connects to | RWP-001, RWP-001SS, RWP-002, RWP-002SS, RWP-006, RWP-006SS, RWP-013, RWP-013SS, RWP-018, RWP-018SS, RWP-030SS |
The RWP-234 is an aluminum riser; base diameter 11.40? and is 4.5” high.
The mounting pad is designed to be used with one standard Raptor dovetail fixture.
The RWP-234 is manufactured from 7075-T6511 aluminum.
Our adapters and risers allow you to attach Raptor Workholding products to any four or five-axis CNC machine. If you need an adapter or riser not seen here, please let us know.
