Brand: DESTACO

DESTACO 035-150-190 PNEUMATIC SWING CLAMP, LESS ARM

SKU: DE-STA-CO-035-150-190
MPN: 035-150-190

$484.82
Unit price per
Save $37.49

Shipping calculated at checkout.

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

Short Description

The SELECT line of pneumatic swing/pull clamps from DESTACO, such as the 035-150-190 model, are ideal for applications that do not require hydraulic power. With a quick-acting design, these clamps can generate up to 50 pounds of clamping force using shop air. The 90 degree swing motion is available in two styles of arms, including a double-locked arm design that provides extra rigidity with its bolted and threaded body construction. This versatile clamp has a 1.180 inch stroke and a cylinder bore of 1.97 inches, with a clamping force of 69 lbf at 5Bar/72psi. The 1/8 NPT AirPort size and low air consumption of 0.023 in³ per double stroke at 7 psi make this clamp a convenient and efficient choice. It also features a 0.63 inch stroke during rotation and 0.55 inch vertical clamp stroke.

*In-stock Destaco products will be shipped within 3 business days. If product doesn't show an in-stock quantity, then average lead times may vary from 2 to 12 weeks, in some cases longer.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

Full Description

DESTACO 035-150-190 PNEUMATIC SWING CLAMP, LESS ARM

A SELECT line of pneumatic swing/pull clamps is designed for applications not requiring hydraulic power. The fast-acting clamps can generate up to 50 pounds of clamping force from shop air.

Swing motion available in 90 degrees
Two styles of arms
Double-locked arm design is bolted to piston shaft and around shaft diameter for extra rigidity
Threaded body for mounting through fixture plates

Stroke (in)	1.180
Cylinder Bore (in)	1.97
Clamping Force @ 5Bar[72Psi] (lbf.)	69
Mount	Threaded Body
Replacement Seal Kit	905519
Swing Direction	RH
AirPort size	1/8 NPT
Air Consumption (per double stroke at 7 psi) (in³)	0.023
Jam Nut	051-250-160
Stroke during rotation (in)	0.63
Vertical clamp stroke (in)	0.55
Sensor Ready	No
Weight (lb)	1.81
Product Series Description	Swing Clamp
Product Function	Clamping
Product Family	Light-Duty Pneumatic Clamping
Product Group	pneumatic swing clamps
