Brand: Iscar
Iscar EH2800753 PHSR 9.5-2.4
SKU: FTS-EH2800753
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.
Short Description
Iscar 2800753 PHSR 9.5-2.4Full Description
| Cutting Width Minimum (CWN) | 0.094" | Coolant Supply Property (CSP) | External |
| Cutting Width Maximum (CWX) | 1/8" | Application | | Ext. Grooving | Ext. Grooving & Turning | Parting | |
| Shank Height (H) | 3/8" | Body Material | Steel |
| Functional Width (WF) | 0.34" | Tool Type | Turn-Groove Tools |
| Head Length (LH) | 0.71" | Measurement Type | Inch |
| Overall Length (OAL) | 5.91" |
Family Description
External machining holders for Swiss-type and automatic machines for GDMW/GDMY inserts
CDX=Max depth capacity, Click "More info" to see the chart
