Brand: Iscar
Iscar EH3202863 MNC 280-140 A32-170-06-5D
SKU: FTS-EH3202863
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.
Short Description
Iscar 3202863 MNC 280-140 A32-170-06-5DFull Description
| Cutting Diameter (DC) | 28 mm | Shank Length (LS) | 60 mm |
| Usable Length (LU) | 143.25 mm | Coolant Supply Property (CSP) | Through Hole |
| Length Group | 5D | Measurement Type | Metric |
| Application | | Drilling | | Master Insert Identification (MIID) | SOGX 060304-W |
| Tool Type | Indexable Insert Drills | Body Material | Steel |
| Connection Diameter Machine Side (DCONMS) | 32 mm | Flange Diameter (DF) | 42 mm |
| Protruding Length (LPR) | 174.3 mm | Body Diameter (BD) | 17 mm |
| Overall Length (OAL) | 234.25 mm | Body Diameter Reduced (BDRED) | 42 mm |
Family Description
Large diameter full effective indexable drills with a pilot drilling head and one flat shanks. Drilling depth 5xD. High drilling rates, high accuracy and surface finish.
Hole tolerance: D+0.10/-0.05 in average conditions. However, it can be higher or lower according to machine and tooling conditions Intermediate sizes are available on request
