Brand: TMX
TMX HK313567004P Live Centers Accuracy .00012 T.I.R. MT4 Adjustable
SKU: FTS-HK313567004P
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.
Short Description
TMX 3-567-004P Live Centers Accuracy .00012 T.I.R. MT4 AdjustableFull Description
| Type | Live Center | Thrust Load | 350 lbs |
| Taper Type | Morse Taper | Accuracy | 0.00012" |
| Point Style | Alloy Steel | Weight | 3.62 lbs |
| Maximum RPM | 4,500 | Model No | 3-567-004P |
| Mount | 4 MT | Point Length | 3.8800" |
| Overall Length | 7.8900" | Style | Adjustable |
| Point Diameter | 1.5300" | Maximum Workpiece Weight | 880 lbs |
| Shank Diameter | 2.3600" |
- Adjustable, ultra precision radial bearing reduces run out to minimum after much use
- Heavy duty
- Triple bearing
- T.I.R. 0.00012"
