Brand: Vardex
Vardex FF674ILN60VKX 4IL N60VKX 1/2 IC - Profile Threading Insert
SKU: FTS-FF674ILN60VKX
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.
Short Description
FF674ILN60VKX 4IL N60VKX 1/2 IC - Profile Threading InsertFull Description
| Inscribed Circle Diameter (IC) | 1/2" | Cutting Position | Internal |
| Thread Pitch (TP) | " 3.5-5.0 | Applicable Material | Stainless Steel|Steel |
| Threads per Inch (TPI) | " 7-5 | Cutting Direction (HAND) | Left Hand |
| Grade | VKX | Tool Type | 60° Partial Profile Threading Insert |
•60° Partial Profile Threading Inserts•The V (partial) - Profile Inserts cut without "topping" the O.D. of the thread. The same insert can be used for a range of different thread pitches. They are stocked in 60° thread angle and are supplied in boxes of 10, with two Allen screws and one key. They are made for Right Hand (RH) and Left Hand (LH), for Internal (IN) and External (EX) threading. To avoid confusion, the different pitch ranges have been defined by letters A, AG, G, N, U, Q, T - see below.•VKX= Submicron grain TiN Coated. Designed for stainless steel, bronze, brass, inconel.
