Brand: Iscar
Iscar EH6412055 ING2047L IC807
SKU: FTS-EH6412055
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.
Short Description
EH6412055 ING2047L IC807Full Description
| Corner Radius (RE) | 0.0035" | Cutting Direction (HAND) | Left Hand |
| Corner Radius Tolerance (+/-) (RETOL) | 0.0012" | Application | | Ext. Grooving | Int. Grooving | |
| Insert Thickness (S) | 0.219" | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | |
| Overall Length (OAL) | 0.514" | Max. Grooving Feed (fg(max)) | 0.002 " /rev |
| Insert Length (INSL) | 0.514" | Min. Grooving Feed (fg(min)) | 0.0012 " /rev |
| Cutting Depth Maximum (CDX) | 0.05" | Insert Rake Angle (GAN) | 0 Degrees |
| Cutting Edge Material | Carbide | Tool Type | Groove-Turn Precision Inserts |
| Coating | TiAlN+TiN | Measurement Type | Inch |
| Grade | IC807 | Body Material | Carbide |
Family Description
Precision double-ended flat top grooving inserts.
DMIN according to related boring bar
