Brand: Iscar
Iscar EH6411924 ING3094RCB IC807
SKU: FTS-EH6411924
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.
Short Description
EH6411924 ING3094RCB IC807Full Description
| Corner Radius (RE) | 0.0075" | Application | | Ext. Grooving | Int. Grooving | |
| Insert Thickness (S) | 0.344" | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | |
| Insert Length (INSL) | 0.89" | Max. Grooving Feed (fg(max)) | 0.0039 " /rev |
| Cutting Depth Maximum (CDX) | 0.18" | Min. Grooving Feed (fg(min)) | 0.0023 " /rev |
| Cutting Edge Material | Carbide | Tool Type | Groove-Turn Precision Inserts |
| Coating | TiAlN+TiN | Measurement Type | Inch |
| Grade | IC807 | Body Material | Carbide |
Family Description
Double-ended precision grooving inserts with a chipformer.
DMIN according to related boring bar.
