Brand: Iscar
Iscar EH2302809 DGTR 19B-3XL-D65
SKU: FTS-EH2302809
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.
Short Description
EH2302809 DGTR 19B-3XL-D65Full Description
| Shank Height (H) | 3/4" | Cutting Position | External |
| Shank Width (B) | 3/4" | Application | | Ext. Grooving | Parting | |
| Body Width (WB) | 0.094" | Body Material | Steel |
| Overall Length (OAL) | 5.91" | Tool Type | Parting & Grooving Tools |
| Head Length (LH) | 1.7" | Cutting Direction (HAND) | Right Hand |
| Cutting Depth Maximum (CDX) | 1.28" | Measurement Type | Inch |
Family Description
Integral shank reinforced parting and grooving tools for parting up to 2.56" diameters.
For insert depth capacity table, click on "More Info"
