Dormer DS047350209 Dormer HSS-E-PM TiAlN/Top SHARK UNC DIN ANSI Machine Tap, White for Cast Iron, Semi Bottoming Straight Flute DIN/ANSI Series E814 E-code # E8143/4

Brand: Dormer

Dormer DS047350209 Dormer HSS-E-PM TiAlN/Top SHARK UNC DIN ANSI Machine Tap, White for Cast Iron, Semi Bottoming Straight Flute DIN/ANSI Series E814 E-code # E8143/4

SKU: FTS-DS047350209
MPN: 7350209

  • $108.78
    Unit price per
  • Save $37.48
Shipping calculated at checkout.

Only 0 left!

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

*This is a Berkshire eSupply item*
Please note, Berkshire has many challenges with delivery dates, discontinued items, etc. Unfortunately, this is beyond our control and we cannot be held responsible for such. Any and all cancelled orders due to circumstances beyond Freers control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.


Short Description

DS047350209 Dormer HSS-E-PM TiAlN/Top SHARK UNC DIN ANSI Machine Tap, White for Cast Iron, Semi Bottoming Straight Flute DIN/ANSI Series E814 E-code # E8143/4

Full Description

Thread Diameter Size (TDZ) 3/4" Tool Type Machine Tap
Threads per Inch (TPI) 10 Coating TiAlN/Top
Thread Standard UNC Tapping Prehole Diameter (Pre-hole) 21/32"
Overall Length (OAL) 4.921" Flute Length 1.181"
Thread Cutting Part Length (THL) 1.181" Flute Type Straight
Connection Diameter Machine Side (DCONMS) 0.59" Style Semi-Bottoming
Flute Count (NOF) 4 Cutting Direction (HAND) Right Hand
Flute Helix Angle (FHA) 0 Degrees Coolant Supply Property (CSP) External
Applicable Material Cast Iron Length Group 2D
Cutting Edge Material HSS-E-PM Square Size 0.439"
Thread Tolerance Class (TCTR) H5 Measurement Type Fractional
Special Feature White Ring Series/List # E814
Standard DIN/ANSI Thread Size " 3/4" - 10
Family Description
E-code # E8143/4
