Brand: Iscar
Iscar EH2301246 DGFH 32-4
SKU: FTS-EH2301246
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.
Short Description
Iscar 2301246 DGFH 32-4
Full Description
| Body Width (WB) | 0.126" | Number of Pocket (NOP) | 2 |
| Cutting Width Minimum (CWN) | 0.157" | Body Material | Steel |
| Cutting Width Maximum (CWX) | 0.157" | Tool Type | Blades and adapters for Parting & Grooving |
| Overall Length (OAL) | 5.906" | Cutting Direction (HAND) | Neutral |
| Cutting Position | External | Measurement Type | Inch |
| Application | | Ext. Grooving | Parting | |
Family Description
Double-ended parting and grooving blades carrying DO-GRIP and HELI-GRIP double-ended inserts. Blades with coolant channels are designated with "C".
DG..1.0 insert can be mounted into pocket sizes 2 and 3, in which case the pocket width has to be modified - click on "More Info"
