Brand: DESTACO
DESTACO VC-F40N-18F 40mm DIA Nitrile Flat Cup - 1/8 NPT Female
SKU: DE-STA-CO-VC-F40N-18F
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
Short Description
Passionately believe in the value of the DESTACO VC-F40N-18F 40mm DIA Nitrile Flat Cup - 1/8 NPT Female, perfect for use on moderately flat to medium contour, dry surfaces. This powerful cup is part of the High-Performance Automation, Workholding, & Containment Solutions catalog from Destaco. Use it on flat surfaces, both dry and moderately oily/slippery, for precise and strong vertical lift. With a holding capacity of 4 kg or 9 lbf, and a 42.2 mm diameter, this black A50 Nitrile cup is ideal for high-precision applications. The round shape and 40 mm (1.57 in) size make it a versatile and essential tool for any project.
*In-stock Destaco products will be shipped within 3 business days. If product doesn't show an in-stock quantity, then average lead times may vary from 2 to 12 weeks, in some cases longer.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
Full Description
DESTACO VC-F40N-18F 40mm DIA Nitrile Flat Cup - 1/8 NPT Female
General purpose micro flatfoot vacuum cups best used on moderatly flat to medium contour, dry surfaces Catalog for High-Performance Automation, Workholding, & Containment Solutions - Destaco
- For relatively flat surfaces.
- Dry to moderate oily/slippery surfaces.
- Low Compression distances.
- Higher precision applications.
| Holding Capacity - Vertical Lift (kg) | 4 |
| Holding Capacity - Vertical Lift (lbf) | 9 |
| Weight (g) | 11.8 |
| Weight (oz) | 0.4 |
| Diameter (mm) | 42.2 |
| Diameter (in) | 1.660 |
| Material | Nitrile |
| Durometer | A50 (Black) |
| Mount | 1/8 G Female |
| Temperature Range | -40° to 275°F (-40° to 135°C) |
| Shape | Round |
| Product Type | Micro Flat |
| Cup Size | 40 mm |
| Cup Size | 1.57 in |
| Product Series Description | Nitrile Rubber |
| Product Function | Robotic Tooling |
| Product Family | End Effectors |
| Product Group | vacuum cups |
