Brand: DESTACO

DESTACO VC-F15N-18F 15MM Flat Nitrile Cup - 1/8 Female Cup Mount

SKU: DE-STA-CO-VC-F15N-18F
MPN: VC-F15N-18F

  • $62.31
    Unit price per
  • Save $7.20
Shipping calculated at checkout.

Only 0 left!

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**


Short Description

Introducing the DESTACO VC-F15N-18F 15MM Flat Nitrile Cup - 1/8 Female Cup Mount - the perfect solution for moderate flat and medium contour surfaces! This high-performance vacuum cup is designed for dry to moderately oily/slippery surfaces, with low compression distances and precise applications in mind. With a holding capacity of up to 1kg (2lbf) in vertical lift, this 16.5mm A50 (Black) nitrile cup is the ideal choice for those seeking precision and reliability. Trust DESTACO for all your automation, workholding, and containment needs - order yours now and experience the difference!

*In-stock Destaco products will be shipped within 3 business days. If product doesn't show an in-stock quantity, then average lead times may vary from 2 to 12 weeks, in some cases longer.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**


Full Description

DESTACO VC-F15N-18F 15MM Flat Nitrile Cup - 1/8 Female Cup Mount

General purpose micro flatfoot vacuum cups best used on moderatly flat to medium contour, dry surfaces Catalog for High-Performance Automation, Workholding, & Containment Solutions - Destaco

  • For relatively flat surfaces.
  • Dry to moderate oily/slippery surfaces.
  • Low Compression distances.
  • Higher precision applications.
Holding Capacity - Vertical Lift (kg) 1
Holding Capacity - Vertical Lift (lbf) 2
Weight (g) 3.4
Weight (oz) 0.1
Diameter (mm) 16.5
Diameter (in) 0.650
Material Nitrile
Durometer A50 (Black)
Mount 1/8 G Female
Temperature Range -40° to 275°F (-40° to 135°C)
Shape Round
Product Type Micro Flat
Cup Size 15 mm
Cup Size 0.59 in
Product Series Description Nitrile Rubber
Product Function Robotic Tooling
Product Family End Effectors
Product Group vacuum cups
