Brand: DESTACO
DESTACO RPW-250M 2 JAW WIDE BODY PARALLEL GRIPPER
SKU: DE-STA-CO-RPW-250M
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
Short Description
DESTACO RPW-250M 2 JAW WIDE BODY PARALLEL GRIPPERWide Body, Parallel Grippers for Harsh Environments - RPW Series. The RPW is designed for handling large size parts that require long finger grip designs. The rack and pinion synchronizer delivers smooth and accurate operation while the rugged design provides long operation life.
*In-stock Destaco products will be shipped within 3 business days. Average lead times may vary from 2 to 12 weeks, in some cases longer.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
Full Description
DESTACO RPW-250M 2 JAW WIDE BODY PARALLEL GRIPPER
The RPW is designed for handling large size parts that require long finger grip designs. The rack and pinion synchronizer delivers smooth and accurate operation while the rugged design provides long operation life.
- Excellent jaw support throughout the full body of the gripper
- High grip forces
- High accuracy and repeatibality
| Imperial or Metric Product | Metric |
| Grip Force (N) | 222 |
| Grip Force (lbsf) | 50 |
| Stroke (mm) | 19.1 |
| Stroke (in) | 0.750 |
| Cylinder Bore (mm) | 15.9 |
| Cylinder Bore (in) | 0.63 |
| Pressure Range (psi) | 40-100 psi |
| Temp Range Standard | -35° to 80°C (-30° to 180°F) |
| Temp Range Viton | -30° to 150°C (-20° to 300°F) |
| Actuation (Open/Closed) (Sec) | 0 |
| Accuracy (±mm) | 0.050 |
| Repeatability (±mm) | 0.030 |
| Repeatability (±in) | 0.001 |
| Maximum Finger Length (mm) | 102 |
| Maximum Finger Length (in) | 4.00 |
| Product Type | 2 Jaw Parallel |
| Special Feature | Heavy Duty |
| Jaw Operation | Non-Synchronous Available |
| Weight (kg) | 0.30 |
| Weight (lb) | 0.66 |
| Product Series Description | Other |
| Number of Jaws | 2 |
| Product Function | Gripping |
| Product Family | Grippers |
| Product Group | Parallel Grippers |
| Brand | Robohand |
| Distributor Group | Robohand Gripping Solutions |
