Brand: DESTACO
DESTACO ROBOHAND RDH-2M 2 JAW PARALLEL GRIPPER
SKU: DE-STA-CO-RDH-2M
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
Short Description
Discover the incredible value of DESTACO RDH-2M 2 JAW PARALLEL GRIPPER - a compact, robust, and powerful tool that will revolutionize your handling capabilities. With superb repeatability and a wide range of applications, this gripper surpasses all expectations. Its shielded design protects against harsh environments and its large jaws provide ample surface area for long fingers. Available in all sizes with two strokes, this product offers a metric grip force of 754N and 153lbsf, and with the added spring assist, reach an impressive 1,006N and 226lbs. With a 6.0mm stroke and cylinder bore of 32mm, this gripper is a testament to precision and reliability. Get your hands on this game-changing tool and see the difference it makes in your work.
*In-stock Destaco products will be shipped within 3 business days. If product doesn't show an in-stock quantity, then average lead times may vary from 2 to 12 weeks, in some cases longer.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
Full Description
DESTACO RDH-2M 2 JAW PARALLEL GRIPPER
This compact, robust and powerful gripper offers excellent repeatibility for precise handling in a wide range of applications.
- Harsh Environment: Shielded design repels chips and other particulate
- All sizes available in two strokes
- Large surface area on jaws allows for long fingers
| Product | Metric |
| Grip Force (N) | 754 |
| Grip Force (lbsf) | 153 |
| Grip Force with Spring Assist (N) | 1,006 |
| Grip Force with Spring Assist (lb) | 226 |
| Stroke (mm) | 6.0 |
| Stroke (in) | 0.240 |
| Cylinder Bore (mm) | 32 |
| Cylinder Bore (in) | 1.26 |
| Pressure Range Without Springs | 30-100 psi |
| Pressure Range With Springs | 65-100 psi |
| Max Vacuum (in. Hg) | 8 |
| Max Vacuum (mm Hg) | 20 |
| Temp Range Standard | -35° to 80°C (-30° to 180°F) |
| Temp Range Viton | -30° to 150°C (-20° to 300°F) |
| Actuation (Open/Closed) (Sec) | 0 |
| Accuracy (±mm) | 0.040 |
| Repeatability (±mm) | 0.020 |
| Repeatability (±in) | 0.001 |
| Maximum Finger Length (mm) | 102 |
| Maximum Finger Length (in) | 4.00 |
| Product Type | 2 Jaw Parallel |
| Clean Room with Scavange | 100 |
| Special Feature | Heavy Duty |
| Jaw Operation | Synchronous |
| Spring Assist | Optional |
| Weight (kg) | 0.53 |
| Weight (lb) | 1.20 |
| Product Series Description | 2-Jaw Parallel Gripper |
| Number of Jaws | 2 |
| Product Function | Gripping |
| Product Family | Grippers |
| Product Group | Parallel Grippers |
| Brand | Robohand |
| Distributor Group | Robohand Gripping Solutions |
