DESTACO CPI-DBD-54-SCMB-150M DBD MOUNT 54MM-BULKHEAD W/150MM SCM

Brand: DESTACO

DESTACO CPI-DBD-54-SCMB-150M DBD MOUNT 54MM-BULKHEAD W/150MM SCM

SKU: DE-STA-CO-CPI-DBD-54-SCMB-150M
MPN: CPI-DBD-54-SCMB-150M

  • $1,651.21
    Unit price per
  • Save $190.88
Shipping calculated at checkout.

Only 0 left!

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**


Short Description

The DESTACO CPI-DBD-54-SCMB-150M is a 54mm bulkhead mount designed for precision in high-performance automation applications. It features an orbital design allowing ±15° compliance without the need for tooling adjustments, ensuring flexibility and ease of use. The mount eliminates compression springs, offering reliable and long-lasting performance. It has a travel range of 150mm, with a total length of 409.4mm (16.12 inches). Equipped with a 3/8 G vacuum port and a bulkhead thread of 1 1/2-18 fine, it supports a sensor diameter of 54mm for enhanced operational accuracy.

*In-stock Destaco products will be shipped within 3 business days. If product doesn't show an in-stock quantity, then average lead times may vary from 2 to 12 weeks, in some cases longer.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**


Full Description

DESTACO CPI-DBD-54-SCMB-150M DBD MOUNT 54MM-BULKHEAD W/150MM SCM

Catalog for High-Performance Automation, Workholding, & Containment Solutions - Destaco

  • Orbital design allows compliance to blanks within +/- 15° without having to make any automation, tooling or robot adjustments. [US Patent No. 4,662,668]
  • Elimination of compression springs results in long-lasting, reliable performance
Product Metric
Length (mm) 409.4
Length (in) 16.120
Product Type Bulkhead Mount
Travel (mm) 150
Vacuum Port 3/8 G
Bulkhead Thread 1 1/2-18 Fine
Sensor Diameter (mm) 54.0
Weight (kg) 0.94
Weight (lb) 2.08
Product Series Description Standard Travel Spring Cup Mount
Product Function Robotic Tooling
Product Family End Effectors
Product Group double blank detectors
Travel (in) 6
