Brand: DESTACO
DESTACO CPI-DBD-54-SCM10-400E DBD MOUNT 54MM- 1in. KNOB - 4in. SCM
SKU: DE-STA-CO-CPI-DBD-54-SCM10-400E
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
Short Description
The DESTACO CPI-DBD-54-SCM10-400E is a 54mm apple core mount designed for automation, workholding, and containment solutions. It features an orbital design that allows for ±15° compliance with blanks, eliminating the need for tooling or robot adjustments. The mount ensures long-lasting, reliable performance due to the elimination of compression springs. It offers a travel range of 100mm and a sensor diameter of 54mm. With a length of 357.8mm (14.12 inches), this mount is ideal for applications requiring precise adjustments and stability.
*In-stock Destaco products will be shipped within 3 business days. If product doesn't show an in-stock quantity, then average lead times may vary from 2 to 12 weeks, in some cases longer.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
Full Description
DESTACO CPI-DBD-54-SCM10-400E DBD MOUNT 54MM- 1in. KNOB - 4in. SCM
Catalog for High-Performance Automation, Workholding, & Containment Solutions - Destaco
- Orbital design allows compliance to blanks within +/- 15° without having to make any automation, tooling or robot adjustments. [US Patent No. 4,662,668]
- Elimination of compression springs results in long-lasting, reliable performance
| Product | Imperial |
| Length (mm) | 357.8 |
| Length (in) | 14.120 |
| Product Type | Apple Core Mount |
| Travel (mm) | 100 |
| Sensor Diameter (mm) | 54.0 |
| Weight (kg) | 0.90 |
| Weight (lb) | 1.97 |
| Product Series Description | Standard Travel Spring Cup Mount |
| Product Function | Robotic Tooling |
| Product Family | End Effectors |
| Product Group | double blank detectors |
| Travel (in) | 4 |
