Brand: Ultra-Dex
Ultra-Dex FG550035 C05KSCLPR1.8 SOLID
SKU: FTS-FG550035
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.
Short Description
Ultra-Dex 920-000-020 C05KSCLPR1.8 SOLIDFull Description
| Connection Diameter Machine Side (DCONMS) | 0.312" | Minimum Bore Diameter (DMIN) | 0.395" |
| Functional Length (LF) | 5" | Cutting Direction (HAND) | Right Hand |
| Overall Length (OAL) | 5" | Minimum Bore Diameter_2 (DMIN_2) | 0.395" |
| Reduced Body Diameter Length (LDRED) | 0.34" | Connection Diameter Workpiece Side (DCONWS) | 0.312" |
| Functional Width (WF) | .219 | Tool Type | Indexable Boring Bar |
| Master Insert Identification (MIID) | CPMT 1.81.20.5 | Style | SCLPR |
• 80° Diamond5° Lead AngleNo Coolant • The highest standards for quality • The braze on our bars is guaranteed not to fail.
