Morse Cutting Tools MT3534621 9/16" - 12 NC 3-Flute, H11 Semi-Bottoming Series/List # 2091 Spiral Flute Tap

Brand: Morse Cutting Tools

Morse Cutting Tools MT3534621 9/16" - 12 NC 3-Flute, H11 Semi-Bottoming Series/List # 2091 Spiral Flute Tap

SKU: FTS-MT3534621
MPN: 34621

Only 0 left!
Please Email SALES For Pricing

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.

Short Description

Morse Cutting Tools 34621 9/16" - 12 NC 3-Flute, H11 Semi-Bottoming Series/List # 2091 Spiral Flute Tap

Full Description

Thread Diameter Size (TDZ) 9/16" Special Feature ShearTap
Threads per Inch (TPI) 12 Standard 0.005" Oversize Tap
Thread Standard NC Tool Type Production Tap
Overall Length (OAL) 3-19/32" Chamfer Semi-Bottoming
Thread Cutting Part Length (THL) 0.69" Coating Steam Oxide Over Nitride
Flute Count (NOF) 3 Flute Type Spiral
Flute Helix Angle (FHA) 48 Degrees Style Semi-Bottoming
Applicable Material Steel | Stainless Steel Measurement Type Fractional
Cutting Edge Material HSS ToolTypeName .005 Oversize Taps
Thread Tolerance Class (TCTR) H11
ShearTapô • ShearTapô - for Stainless Steel & Carbon Steel up to 35Rc hardness. • Oversize taps are mainly used for parts that will be plated or heat treated after tapping. Also used in materials that tend to shrink after tapping. • CNC Style enchances chip evacuation and cutting fluid flow to the cutting teeth for reduced friction, heat and galling. Also reduces contact between the tap and the workpiece. • Semi-Bottoming Style are designed to lift the chips sout of the hole in blind hole tapping, eliminating chip evacuation problems which can result in damaged threads and broken taps. They will also bridge opeings, keyways and other interruptions in the tapped hole. • Steam Oxide over Nitride increases wear resistance, reduces friction, reduces galling and chip welding, improves chip flow and increases tap lubricant retention.
