Brand: JW Winco
JW WINCO GN743.6-18-M27X1.5 OIL SIGHT GLASS ALUM ATEX EXPLOSION PROTECTION
SKU: JW-743.6-18-M27X1.5
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
Short Description
JW WINCO GN743.6-18-M27X1.5 OIL SIGHT GLASS ALUM ATEX EXPLOSION PROTECTIONGN 743.6 the European guidelines for explosion protection introduced on 7/1/03 (ATEX) also cover explosion protection in the mechanical sector. Fluid level sight glasses GN 743.6 are suitable for use in an explosion risk environment, and comply with guidelines 2014/34/EU. Detailed documentation accompanies this part when ordered. Features include genuine glass of high stability and scratch proof, sealing with an O-ring on the periphery and not on the face edge of the glass, leak tightness is therefore not affected by axial pressures. Seal is housed in a groove and therefore cannot be lost. Meanwhile, this groove prevents the seal from being extruded when the sight glass is tightened. The location of this seal also allows the use of a softer Elastomer, which guarantees better and easier sealing, heat resistance -20°C (-4°F) to 150°C (300°F).
Aluminum Body, ESG glass Sight Glass
FPM Rubber Seal with Stainless Steel Retaining Ring
GN 743.6 Standard Sheet
*All JW Winco orders must meet a $75 minimum or there will be a $10 processing fee.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
Full Description
JW WINCO GN743.6-18-M27X1.5 OIL SIGHT GLASS ALUM ATEX EXPLOSION PROTECTION
GN 743.6 the European guidelines for explosion protection introduced on 7/1/03 (ATEX) also cover explosion protection in the mechanical sector. Fluid level sight glasses GN 743.6 are suitable for use in an explosion risk environment, and comply with guidelines 2014/34/EU. Detailed documentation accompanies this part when ordered. Features include genuine glass of high stability and scratch proof, sealing with an O-ring on the periphery and not on the face edge of the glass, leak tightness is therefore not affected by axial pressures. Seal is housed in a groove and therefore cannot be lost. Meanwhile, this groove prevents the seal from being extruded when the sight glass is tightened. The location of this seal also allows the use of a softer Elastomer, which guarantees better and easier sealing, heat resistance -20°C (-4°F) to 150°C (300°F).
Body: Aluminum
Sight Glass: ESG glass
Seal: FPM Rubber
Retaining Ring: Stainless Steel
Window Dia.: 0.71"
Thread: M27
Overall Dia.: 1.26"
Thread Length: 0.35"
Head Height: 0.43"
*All JW Winco orders must meet a $75 minimum or there will be a $10 processing fee.*
