Brand: Vardex

Vardex FF605ILQ60VKX 5ILQ60VKX 5/8 IC - Profile Threading Insert

SKU: FTS-FF605ILQ60VKX
MPN: 59013

$43.65
Unit price per

Shipping calculated at checkout.

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

*This is a Berkshire eSupply item*
Please note, Berkshire has many challenges with delivery dates, discontinued items, etc. Unfortunately, this is beyond our control and we cannot be held responsible for such. Any and all cancelled orders due to circumstances beyond Freers control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.

Short Description

Vardex 59013 5ILQ60VKX 5/8 IC - Profile Threading Insert

Full Description

Inscribed Circle Diameter (IC)	5/8"	Cutting Position	Internal
Thread Pitch (TP)	5.5-6	Applicable Material	Stainless Steel\|Steel
Threads per Inch (TPI)	4.5-4	Cutting Direction (HAND)	Left Hand
Grade	VKX	Tool Type	60° Partial Profile Threading Insert

• 60° Partial Profile Threading Inserts • The V (partial) - Profile Inserts cut without "topping" the O.D. of the thread. The same insert can be used for a range of different thread pitches. They are stocked in 60° thread angle and are supplied in boxes of 10, with two Allen screws and one key. They are made for Right Hand (RH) and Left Hand (LH), for Internal (IN) and External (EX) threading. To avoid confusion, the different pitch ranges have been defined by letters A, AG, G, N, U, Q, T - see below. • VKX= Submicron grain TiN Coated. Designed for stainless steel, bronze, brass, inconel.
