Eccentric Clamp - 23271.0008

Brand: HALDER

Eccentric Clamp - 23271.0008

SKU: EH-23271.0008
MPN: 23271.0008

  • $38.23
    Unit price per
  • Save $1.99
Shipping calculated at checkout.

Only 0 left!

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**


*Please note, there is a $50 minimum for all Halder product orders*

Short Description

Eccentric Clamps 23271.0008.
EH 23271
The eccentric clamp allows clamping with pull-down effect on different workpiece forms at low height.
Halder 23271.0008 Data Sheet

*Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.*

Full Description

The eccentric clamp allows clamping with pull-down effect on different workpiece forms at low height.

Material

  • Case-hardened steel, case-hardened and blue zinc-plated

Assembly

  • Manufacture a thread with the corresponding distance L2 / L3 to the workpiece.
  • Screw in the eccentric clamp at the necessary height and set it relative to the workpiece with its flat side.
  • Insert the workpiece and tighten the clamping pin using the internal hexagon. The proper tension is achieved after approx. 1/3 turn.

The threaded hole must be lubricated on a regular basis.

The rotational movement during tightening must always be completed towards the stops in order to prevent the workpiece from turning away from the stops.

Halder 23271.0008 Data Sheet
