Morse Cutting Tools MT3594652 1-3/8-8 Dia. - H5 - 4 FL - HSS - TiN - Plug - Spiral Point Tap Series/List #2090G

Brand: Morse Cutting Tools

Morse Cutting Tools MT3594652 1-3/8-8 Dia. - H5 - 4 FL - HSS - TiN - Plug - Spiral Point Tap Series/List #2090G

SKU: FTS-MT3594652
MPN: 94652

Only 0 left!
Please Email SALES For Pricing

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.

Short Description

Morse Cutting Tools 94652 1-3/8-8 Dia. - H5 - 4 FL - HSS - TiN - Plug - Spiral Point Tap Series/List #2090G

Full Description

Thread Standard NC Tool Type Production Tap
Thread Size 1-3/8" - 8 Special Feature ShearTap
Thread Diameter Size (TDZ) 1-3/8" Applicable Material Steel | Stainless Steel
Threads per Inch (TPI) 8 Thread Cutting Part Length (THL) 2"
Thread Tolerance Class (TCTR) H5 Flute Type Straight
Usable Length (LU) 2" End Shape Spiral Point
Overall Length (OAL) 6-1/16" Style Plug
Chamfer 3 to 5 Threads Cutting Direction (HAND) Right
Coating TiN Coolant Supply Property (CSP) External
Flute Count (NOF) 4 Measurement Type Fractional
Cutting Edge Material HSS Series/List # 2090G
ShearTapô • ShearTapô - for Stainless Steel & Carbon Steel up to 35Rc hardness. • CNC Style enchances chip evacuation and cutting fluid flow to the cutting teeth for reduced friction, heat and galling. Also reduces contact between the tap and the workpiece. • Spiral Point Taps are designed for efficient tapping of through holes and blind holes with adequate depth for chip accumulation at the bottom of the hole. The shearing action of the point provides freer cutting action and ejects the chips ahead of the tap, eliminating chip evacuation problems and chip damage to the threads. Shallower flutes also result in greater tap strength, allowing for higher cutting speeds. • TiN - Titanium Nitride increases wear resistance, reduces friction and galling, reduces tapping torque, improves thread quality, and allows increased cutting speeds. Productivity and tool life are improved.
