Morse Cutting Tools MT3594661 1-1/4" - 8 NC 4-Flute, H5 Bottoming Series/List # 2091G Spiral Flute Tap

Brand: Morse Cutting Tools

Morse Cutting Tools MT3594661 1-1/4" - 8 NC 4-Flute, H5 Bottoming Series/List # 2091G Spiral Flute Tap

SKU: FTS-MT3594661
MPN: 94661

Only 0 left!
Please Email SALES For Pricing

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.

Short Description

Morse Cutting Tools 94661 1-1/4" - 8 NC 4-Flute, H5 Bottoming Series/List # 2091G Spiral Flute Tap

Full Description

Thread Diameter Size (TDZ) 1-1/4" Tool Type High Performance Tap
Threads per Inch (TPI) 8 Chamfer Semi-Bottoming
Thread Standard NC Coating TiN
Overall Length (OAL) 5-3/4" Flute Type Spiral-48 Degree
Thread Cutting Part Length (THL) 1.143" Style Bottoming
Flute Count (NOF) 4 Measurement Type Fractional
Cutting Edge Material HSS ToolTypeName Spiral Flute Taps
Thread Tolerance Class (TCTR) H5
ShearTapô • ShearTapô for Stainless Steel & Carbon Steel up to 35Rc hardness. • CNC Style enchances chip evacuation and cutting fluid flow to the cutting teeth for reduced friction, heat and galling. Also reduces contact between the tap and the workpiece. • Semi-Bottoming Style are designed to lift the chips sout of the hole in blind hole tapping, eliminating chip evacuation problems which can result in damaged threads and broken taps. They will also bridge opeings, keyways and other interruptions in the tapped hole. • TiN Coating - Titanium Nitride increases wear resistance, reduces firiction and galling, reduces tapping torque, improves thread quality, and allows increased cutting speeds. Productivity and tool life are improved.
