NAAMS Hex Head Screw F052432B M24-3.0 x 180
SKU: FN-F052432B
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*In-Stock NAAMS will ship within 1-5 business days. Otherwise lead times are at least 2-4 weeks.*
**If timing is critical, please call 586-463-3200 to discuss time-frame before placing your order.**
Looking for CAD models?
Request NAAMS CAD Models
Request NAAMS CAD Models
Short Description
Enhance your product assembly with the NAAMS Hex Head Screw F052432B. These fastener components, part of the F05 series, come in M24-3.0 x 180 size and pitch, crafted from class 10.9 steel and coated in a sleek blue finish.
Full Description
FREER NAAMS HEX HEAD SCREW F052432B
Material: Class 10.9 Steel
Blue Coated
Size, Pitch, and Length: M24-3.0 x 180
| Screw dia. & thread pitch |
D | S | E | K | C | |||||
| Max | Min | Max | Min | Max | Min | Max | Min | Max | Min | |
| M24x3 | 24 | 23.67 | 36 | 35 | 41.57 | 39.55 | 15.44 | 14.56 | 0.8 | 0.4 |
