Brand: FREER NAAMS
NAAMS Hex Head Screw F052036B M20-2.5 x 220
SKU: FN-F052036B
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*In-Stock NAAMS will ship within 1-5 business days. Otherwise lead times are at least 2-4 weeks.*
**If timing is critical, please call 586-463-3200 to discuss time-frame before placing your order.**
Request NAAMS CAD Models
Short Description
Experience the exceptional quality and strength of NAAMS Hex Head Screw F052036B fastener components. These hex head screws from the F05 series come in a size of M20-2.5 x 220 and are made from class 10.9 steel with a sleek blue coating. Trust in the reliability and durability of this top-notch product.
Full Description
FREER NAAMS HEX HEAD SCREW F052036B
Material: Class 10.9 Steel
Blue Coated
Size, Pitch, and Length: M20-2.5 x 220
| Screw dia. & thread pitch |
D | S | E | K | C | |||||
| Max | Min | Max | Min | Max | Min | Max | Min | Max | Min | |
| M20x2.5 | 20 | 19.67 | 30 | 29.16 | 34.64 | 32.95 | 12.88 | 12.12 | 0.8 | 0.4 |
