Brand: FREER NAAMS
NAAMS Base Robot Riser ARR740
SKU: FN-ARR740
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*In-Stock NAAMS will ship within 1-5 business days. Otherwise lead times are at least 2-4 weeks.*
**If timing is critical, please call 586-463-3200 to discuss time-frame before placing your order.**
Request NAAMS CAD Models
Short Description
Introducing the incredible NAAMS Base Robot Riser ARR740, now available for you! Enjoy a generous A±3: 1600mm, a compact B: 1498.4mm, and a versatile C: 910mm. With a Hole Detail of M24 X 2, and a Mounting System # of 6, this riser is perfect for all your needs. Weighing in at only 3751 kg, this is the ultimate addition to your arsenal. Don't miss out on this must-have product!
Full Description
FREER NAAMS BASE ROBOT RISER ARR740
A±3: 1600mm
B: 1498.4mm
C: 910mm
Hole Detail: M24 X 2
Mounting System #: 6
Wt. kg: 3751
For mounting and leveling instructions, click here: NAAMS Robot Riser Mounting and Leveling Instructions
For optional leveling plates, follow the corresponding NAAMS code:
ABL343
ABL643
ABL843
ABL340
ABL341
ABL440
ABL441
