Brand: FREER NAAMS
NAAMS Flat Bracket AFB117
SKU: FN-AFB117
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*In-Stock NAAMS will ship within 1-5 business days. Otherwise lead times are at least 2-4 weeks.*
**If timing is critical, please call 586-463-3200 to discuss time-frame before placing your order.**
Request NAAMS CAD Models
Short Description
Experience the exceptional quality of NAAMS Flat Bracket AFB117 with a 125mm Bolt Circle. Made of top-grade ASTM A-36 Steel Plate and ASTM A-513 Type 5 Steel Tubing, this bracket measures a 20 x 150mm diameter and features a 90mm diameter,10mm wall thickness, and a height of 550mm. This sturdy and durable bracket weighs in at only 12.9kg, making it a versatile and efficient choice for all your industrial needs.
Full Description
FREER NAAMS FLAT BRACKET AFB117
125mm Bolt Circle on Wrist
Material: a - ASTM A-36 Steel Plate, b - ASTM A-513 Type 5 Steel Tubing
Dimensions: a - 20 x 150mm Dia, b - 90 Dia x 10mm W/T x "A"
Height: 550mm
A: 518mm
Wt. kg: 12.9
