Brand: FREER NAAMS
NAAMS Flat Bracket AFB106
SKU: FN-AFB106
MPN:
*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**
*In-Stock NAAMS will ship within 1-5 business days. Otherwise lead times are at least 2-4 weeks.*
**If timing is critical, please call 586-463-3200 to discuss time-frame before placing your order.**
Request NAAMS CAD Models
Short Description
The AFB106 NAAMS Flat Bracket features a 125mm bolt circle on a strong steel plate or tubing. Its dimensions include a 20 x 150mm diameter and a 90mm outer diameter with a 10mm thickness. With an impressive height of 275mm and a weight of 7.9 kg, this bracket is a sturdy and reliable choice for any project.
Full Description
FREER NAAMS FLAT BRACKET AFB106
125mm Bolt Circle on Wrist
Material: a - ASTM A-36 Steel Plate, b - ASTM A-513 Type 5 Steel Tubing
Dimensions: a - 20 x 150mm Dia, b - 90 Dia x 10mm W/T x "A"
Height: 275mm
A: 243mm
Wt. kg: 7.9
