Brand: Iscar

Iscar EH3603460 PCLNR 12-3X

SKU: FTS-EH3603460
MPN: 3603460

$137.97
Unit price per

Shipping calculated at checkout.

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

*This is a Berkshire eSupply item*
Please note, Berkshire has many challenges with delivery dates, discontinued items, etc. Unfortunately, this is beyond our control and we cannot be held responsible for such. Any and all cancelled orders due to circumstances beyond Freers control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.

Short Description

Iscar 3603460 PCLNR 12-3X

Full Description

Shank Height (H)	3/4"	Rake Angle Axial (GAMP)	6 Degrees
Shank Width (B)	3/4"	Rake Angle Radial (GAMF)	-6 Degrees
Functional Length (LF)	4-1/2"	Body Material	Steel
Head Length (LH)	1"	Cutting Position	External
Functional Width (WF)	1"	Tool Type	Square Shank Turning Tools
Inscribed Circle Diameter (IC)	3/8"	Measurement Type	Inch
Cutting Direction (HAND)	Right Hand	Style	PCLNR123X
Master Insert Identification (MIID)	CNMX 34. CNMG 33.	Insert Style	4.5"
Application	\| Ext. 80° Diamond 95° Approach \|

Family Description

Lever lock tools carrying the CNMX/CNMG 80° rhombic inserts.

Supplied with TCX 3 seat for CNMX 34. inserts and TCN 323 seat for CNMG 33. inserts, TCX 4 seat for CNMX 45. inserts and TCN 443 seat for CNMG 43. inserts, TCX 5 seat for CNMX 55. inserts and TCN 53 seat for CNMG 54. inserts.
