Brand: Rego-Fix

Rego-Fix GM20885316081 CAT50 x ER32 x 10" Collet Chuck

SKU: FTS-GM20885316081
MPN: 8853.16081

$1,490.99
Unit price per

Shipping calculated at checkout.

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

*This is a Berkshire eSupply item*
Please note, Berkshire has many challenges with delivery dates, discontinued items, etc. Unfortunately, this is beyond our control and we cannot be held responsible for such. Any and all cancelled orders due to circumstances beyond Freers control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.

Short Description

Rego-Fix 8853.16081 CAT50 x ER32 x 10" Collet Chuck

Full Description

Shank Size (SS)	#50	Style	Standard
Connection Size (CSI)	#32	Coolant Supply Property (CSP)	Coolant Thru
Body Diameter (BD)	1.970"	Type	ER
Protruding Length (LPR)	10"	Measurement Type	Inch
Body Length (LB)	4"	Nut Diameter	1.97"
Connection Diameter Machine Side (DCONMS)	2.05"	Length Group	XL
Tool Type	Collet Chucks

• For lengths up to 14 • Special design dampens vibrations better than solid body designs • Case hardened to 58–62 HRc for long life and wear resistances • Pre-balanced to 5,000 rpms. • TIR from the collet cavity to the holder taper 0.0004 or better • Lot Numbers for lot traceability • Precision threads for better clamping force and accuracy • Through the spindle coolant or through the flange version available • REGO-FIX Hi-Q nut provided for added clamping force.
